Description & Specs

Specifications

Brand Bosch
MPN 1986S00789
Bore diameter [mm] 12.5 mm
Bore diameter 2 [mm] 12.5 mm
Bore Ø 3 [mm] 12.5 mm
Clamp 30,50
Flange diameter [mm] 76.2 mm
Length [mm] 211 mm
Mounting Angle [degrees] 44 °
Mounting bore angle measurement [degree] 44 °
Number of mounting bores 3
Number of Teeth 10
Pinion Rest Position [mm] 52 mm
Position/Degree links °
Rated Power [kW] 1.7 kW
Starter Type Floating pinion
Voltage [V] 12 V
// 03 COMPATIBILITY

Fits 57 vehicles

Verified against TecDoc. Expand a model to see variants, or use the search to narrow down.

Audi
17 variants · 6 models
Date Badge Chassis Body Fuel Engine
05/2010 - 04/2015 1.4 TFSI 8X1, 8XK Hatchback Petrol 1.4 TFSI 1.4L 90kW

05/2010 - 04/2015 1.4 TFSI 8X1, 8XK Hatchback Petrol 1.4 TFSI 1.4L 90kW

Date Badge Chassis Body Fuel Engine
11/2011 - 04/2015 1.4 TFSI 8XA, 8XF Hatchback Petrol 1.4 TFSI 1.4L 90kW

11/2011 - 04/2015 1.4 TFSI 8XA, 8XF Hatchback Petrol 1.4 TFSI 1.4L 90kW

Date Badge Chassis Body Fuel Engine
05/2003 - 06/2008 2.0 FSI 8P1 Hatchback Petrol 2.0 FSI 2.0L 110kW

05/2003 - 06/2008 2.0 FSI 8P1 Hatchback Petrol 2.0 FSI 2.0L 110kW

11/2006 - 08/2012 1.8 TFSI 8P1 Hatchback Petrol 1.8 TFSI 1.8L 118kW

11/2006 - 08/2012 1.8 TFSI 8P1 Hatchback Petrol 1.8 TFSI 1.8L 118kW

09/2007 - 08/2012 1.4 TFSI 8P1 Hatchback Petrol 1.4 TFSI 1.4L 92kW

04/2008 - 05/2013 1.8 TFSI 8P7 Convertible Petrol 1.8 TFSI 1.8L 118kW

04/2008 - 05/2013 1.8 TFSI 8P7 Convertible Petrol 1.8 TFSI 1.8L 118kW

Date Badge Chassis Body Fuel Engine
09/2004 - 06/2008 2.0 FSI 8PA Hatchback Petrol 2.0 FSI 2.0L 110kW

11/2006 - 03/2013 1.8 TFSI 8PA Hatchback Petrol 1.8 TFSI 1.8L 118kW

11/2006 - 03/2013 1.8 TFSI 8PA Hatchback Petrol 1.8 TFSI 1.8L 118kW

09/2007 - 03/2013 1.4 TFSI 8PA Hatchback Petrol 1.4 TFSI 1.4L 92kW

Date Badge Chassis Body Fuel Engine
06/2008 - 06/2014 1.8 TFSI 8J3 Coupe Petrol 1.8 TFSI 1.8L 118kW

Date Badge Chassis Body Fuel Engine
06/2008 - 06/2014 1.8 TFSI 8J9 Convertible Petrol 1.8 TFSI 1.8L 118kW

Skoda
12 variants · 4 models
Date Badge Chassis Body Fuel Engine
11/2004 - 10/2008 2.0 FSI 1Z3 Hatchback Petrol 2.0 FSI 2.0L 110kW

11/2004 - 10/2008 2.0 FSI 1Z3 Hatchback Petrol 2.0 FSI 2.0L 110kW

06/2007 - 04/2013 1.8 TSI 1Z3 Hatchback Petrol 1.8 TSI 1.8L 118kW

11/2008 - 06/2013 1.4 TSI 1Z3 Hatchback Petrol 1.4 TSI 1.4L 90kW

Date Badge Chassis Body Fuel Engine
11/2004 - 10/2008 2.0 FSI 1Z5 Wagon Petrol 2.0 FSI 2.0L 110kW

11/2004 - 10/2008 2.0 FSI 1Z5 Wagon Petrol 2.0 FSI 2.0L 110kW

11/2004 - 04/2009 2.0 FSI 4x4 1Z5 Wagon Petrol 2.0 FSI 4x4 2.0L 110kW

06/2007 - 04/2013 1.8 TSI 1Z5 Wagon Petrol 1.8 TSI 1.8L 118kW

11/2008 - 06/2013 1.4 TSI 1Z5 Wagon Petrol 1.4 TSI 1.4L 90kW

Date Badge Chassis Body Fuel Engine
03/2008 - 05/2015 1.8 TSI 3T4 Hatchback Petrol 1.8 TSI 1.8L 118kW

10/2009 - 05/2015 1.8 TSI 3T5 Wagon Petrol 1.8 TSI 1.8L 118kW

Date Badge Chassis Body Fuel Engine
06/2010 - 05/2015 1.4 TSI 5L Suv Petrol 1.4 TSI 1.4L 90kW

VW
28 variants · 15 models
Date Badge Chassis Body Fuel Engine
10/2011 - 07/2016 1.4 TSI 5C1, 5C2 Hatchback Petrol 1.4 TSI 1.4L 118kW

Date Badge Chassis Body Fuel Engine
08/2004 - 11/2008 2.0 FSI 1K1 Hatchback Petrol 2.0 FSI 2.0L 110kW

08/2004 - 11/2008 2.0 FSI 1K1 Hatchback Petrol 2.0 FSI 2.0L 110kW

11/2005 - 11/2008 1.4 GT Sport TSI 1K1 Hatchback Petrol 1.4 GT Sport TSI 1.4L 125kW

05/2007 - 11/2008 1.4 TSI 1K1 Hatchback Petrol 1.4 TSI 1.4L 90kW

Date Badge Chassis Body Fuel Engine
10/2008 - 11/2012 1.4 TSI 5K1 Hatchback Petrol 1.4 TSI 1.4L 90kW

10/2008 - 11/2012 1.4 TSI 5K1 Hatchback Petrol 1.4 TSI 1.4L 118kW

07/2011 - 05/2016 1.4 TSI 517 Convertible Petrol 1.4 TSI 1.4L 118kW

Date Badge Chassis Body Fuel Engine
07/2009 - 07/2013 1.4 TSI AJ5 Wagon Petrol 1.4 TSI 1.4L 90kW

07/2009 - 07/2013 1.4 TSI AJ5 Wagon Petrol 1.4 TSI 1.4L 118kW

Date Badge Chassis Body Fuel Engine
08/2005 - 10/2010 2.0 FSI 1K2 Sedan Petrol 2.0 FSI 2.0L 110kW

07/2008 - 10/2010 1.4 TSI 1K2 Sedan Petrol 1.4 TSI 1.4L 118kW

Date Badge Chassis Body Fuel Engine
04/2011 - 12/2017 1.4 TSI 162, 163, AV3, AV2 Sedan Petrol 1.4 TSI 1.4L 118kW

Date Badge Chassis Body Fuel Engine
03/2005 - 07/2010 2.0 FSI 3C2 Sedan Petrol 2.0 FSI 2.0L 110kW

03/2005 - 07/2010 2.0 FSI 3C2 Sedan Petrol 2.0 FSI 2.0L 110kW

05/2007 - 07/2010 1.8 TSI 3C2 Sedan Petrol 1.8 TSI 1.8L 118kW

05/2007 - 07/2010 1.8 TSI 3C2 Sedan Petrol 1.8 TSI 1.8L 118kW

Date Badge Chassis Body Fuel Engine
05/2007 - 10/2011 1.8 TSI 3C5 Wagon Petrol 1.8 TSI 1.8L 118kW

05/2007 - 10/2011 1.8 TSI 3C5 Wagon Petrol 1.8 TSI 1.8L 118kW

Date Badge Chassis Body Fuel Engine
08/2010 - 12/2014 1.8 TSI 362 Sedan Petrol 1.8 TSI 1.8L 118kW

Date Badge Chassis Body Fuel Engine
08/2010 - 12/2014 1.8 TSI 365 Wagon Petrol 1.8 TSI 1.8L 118kW

Date Badge Chassis Body Fuel Engine
09/2004 - 12/2006 1.6 Classic 9N2, 9N4 Sedan Petrol 1.6 Classic 1.6L 74kW

09/2005 - 11/2009 1.8 GTI 9N, 9A Hatchback Petrol 1.8 GTI 1.8L 110kW

Date Badge Chassis Body Fuel Engine
10/2003 - 01/2007 2.0 FSI 1T1, 1T2 Mpv Petrol 2.0 FSI 2.0L 110kW

05/2004 - 01/2007 2.0 FSI 1T1, 1T2 Box body/mpv Petrol 2.0 FSI 2.0L 110kW

Date Badge Chassis Body Fuel Engine
11/2003 - 02/2010 2.0 7HB, 7HJ, 7EB, 7EJ Bus Petrol 2.0 2.0L 85kW

Date Badge Chassis Body Fuel Engine
11/2003 - 08/2015 2.0 7HA, 7HH, 7EA, 7EH Van Petrol 2.0 2.0L 85kW

Date Badge Chassis Body Fuel Engine
11/2003 - 05/2013 2.0 TRANSPORTER T5 (7JD, 7JE, 7JL, 7JY, 7JZ, 7F Platform/chassis Petrol 2.0 2.0L 85kW

Manufacturer Numbers
AUDI 02Z911023G , 02Z911024P
SEAT 02Z911023E , 02Z911023G , 02Z911024P
SKODA 02Z911023E , 02Z911023G , 02Z911024P
VW 02Z911023E , 02Z911023EX , 02Z911023G , 02Z911023GX , 02Z911024P
Brand References
BOSCH 0 986 020 240
VALEO 438171
